| Healthcare and Pharmaceutical Industries | Aseptic workshops, clean operating rooms, biosafety laboratories |
| Electronics and Semiconductor Industries | Wafer manufacturing workshops, variable air volume (VAV) systems. |
| Number | Model | L mm | W mm | H mm | Area m² | Airflow.pressure drop | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| 0.75m/s | H13(Pa) | H14(Pa) | 1.0m/s | H13(Pa) | H14(Pa) | ||||||
| 1 | Y13320320150 | 320 | 320 | 150 | 2.9 | 276 | 200 | 220 | 369 | 250 | 275 |
| 2 | Y13484484150 | 484 | 484 | 150 | 6.6 | 632 | 200 | 220 | 843 | 250 | 275 |
| 3 | Y13595595150 | 595 | 595 | 150 | 9.9 | 956 | 200 | 220 | 1274 | 250 | 275 |
| 4 | Y13610610150 | 610 | 610 | 150 | 10.4 | 1005 | 200 | 220 | 1340 | 250 | 275 |
| 5 | Y131220610150 | 1220 | 610 | 150 | 20.8 | 2009 | 200 | 220 | 2679 | 250 | 275 |
| 6 | Y13320320220 | 320 | 320 | 220 | 4.4 | 276 | 150 | 165 | 369 | 220 | 242 |
| 7 | Y13484484220 | 484 | 484 | 220 | 10.1 | 632 | 150 | 165 | 843 | 220 | 242 |
| 8 | Y13595595220 | 595 | 595 | 220 | 15.2 | 956 | 150 | 165 | 1274 | 220 | 242 |
| 9 | Y13610610220 | 610 | 610 | 220 | 16.0 | 1005 | 150 | 165 | 1340 | 220 | 242 |
| 10 | Y131220610220 | 1220 | 610 | 220 | 32.0 | 2009 | 150 | 165 | 2679 | 220 | 242 |
| Number | Model | mm | mm | mm | m² | 1.5m/s | H13(Pa) | H14(Pa) | 2.5m/s | H13(Pa) | H14(Pa) |
| 11 | Y13320320292 | 320 | 320 | 292 | 5.9 | 553 | 250 | 275 | 922 | 350 | 385 |
| 12 | Y13484484292 | 484 | 484 | 292 | 13.6 | 1265 | 250 | 275 | 2108 | 350 | 385 |
| 13 | Y13595595292 | 595 | 595 | 292 | 20.5 | 1912 | 250 | 275 | 3186 | 350 | 385 |
| 14 | Y13610610292 | 610 | 610 | 292 | 21.6 | 2009 | 250 | 275 | 3349 | 350 | 385 |
| 15 | Y131220610292 | 1220 | 610 | 292 | 43.2 | 4019 | 250 | 275 | 6698 | 350 | 385 |
If H14 filter paper is used, please change "Y13" in the model number to "Y14"; refer to the H14 (Pa) column for resistance values, while all other specifications remain the same.
Note: Pressure drop ±15%
